4-Wheel Electric Counterbalance Forklift for Warehousing & Industrial Operations
The TKE Series electric counterbalance forklift is engineered to transform material handling operations across warehouses, distribution centers, and industrial facilities. Available in six capacity configurations ranging from 1,000 kg to 5,000 kg, this electric counterbalance forklift combines energy-saving technology, ergonomic design, and intelligent diagnostics to deliver superior performance in demanding work environments.
With the global electric forklift market projected to reach $80.42 billion in 2026 and electric models now accounting for over 70% of new truck sales in major markets, the shift toward electrification is accelerating. The TKE Series positions your operation at the forefront of this transformation—delivering zero-emission performance without compromising power or productivity.
Technical Specifications
Parameter | TKE10 | TKE15 | TKE20 | TKE30 | TKE35 | TKE50 |
Drive Unit | Electric | Electric | Electric | Electric | Electric | Electric |
Operator Type | Rider | Rider | Rider | Rider | Rider | Rider |
Rated Capacity [kg] | 1000 | 1500 | 2000 | 3000 | 3500 | 5000 |
Load Center Distance [mm] | 450 | 500 | 600 | 600 | 600 | 600 |
Wheelbase [mm] | 1100 | 1320 | 1580 | 1880 | 1880 | 1930 |
Tilt Angle [°] | 6/12 | 6/12 | 6/12 | 6/12 | 6/12 | 6/12 |
Deadweight [kg] | 1674 | 2288 | 2680 | 3950 | 4630 | 7530 |
Total Length [mm] | 2635 | 3010 | 3290 | 3645 | 3640 | 4195 |
Total Width [mm] | 1020 | 1020 | 1160 | 1305 | 1305 | 1590 |
Overall Height (Mast Lowered) [mm] | 2000 | 2100 | 2150 | 2110 | 2110 | 2370 |
Overall Height (Mast Raised) [mm] | 3800 | 3830 | 3830 | 3830 | 3830 | 4255 |
Lifting Height [mm] | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 |
Overhead Guard Height [mm] | 1950 | 1950 | 2150 | 2180 | 2180 | 2370 |
Front Overhang [mm] | 370 | 370 | 425 | 530 | 530 | 570 |
Fork Size [mm] | 100/35/920 | 100/35/1070 | 100/35/1070 | 125/45/1070 | 125/45/1070 | 125/45/1070 |
Fork Width (Adjustable) [mm] | 200-1000 | 200-1000 | 200-1000 | 250-1000 | 250-1000 | 250-1000 |
Ground Clearance [mm] | 90 | 90 | 120 | 120 | 120 | 225 |
Right-Angle Stacking Aisle Width [mm] | 3050 | 3275 | 3955 | 4345 | 4345 | 5367 |
Turning Radius [mm] | 1690 | 1915 | 2260 | 2545 | 2545 | 3375 |
Why Global Businesses Choose Our TKE 4-Wheel Electric Counterbalance Forklifts
Our 4-wheel counterbalance forklift stands out in the competitive global market due to four core engineering advantages:
Panoramic Wide-Field Vision: Standard wide field-of-view mast combined with an optimized overhead guard structure significantly improves upward and forward visibility, maximizing workplace safety.
Superior Energy Efficiency: Equipped with dedicated low-rolling-resistance electric tires (saving over 10% on driving energy) and high-efficiency LED signal lights (saving 80% on lighting energy), extending overall battery runtime by roughly 10%.
All-Day Operator Comfort: Fully adjustable steering wheel and suspension seat alleviate operator strain. The ratchet-type handbrake offers adaptive braking force for both slopes and flat floors, effectively mitigating fatigue.
Smart Diagnostics & Easy Maintenance: An intuitive large LCD screen displays real-time vehicle status, complete with fault detection and error warnings. A removable side panel gives technicians direct, hassle-free access to the electronic control system.
Ideal Applications
The TKE Series electric counterbalance forklifts are widely utilized in:
Warehousing & Distribution Centers – Efficient goods handling and inventory management
Manufacturing Workshops – Raw material feeding and finished product transport
Food & Beverage Industry – Zero-emission, hygienic operation
Electronics Assembly – Precision handling in clean environments
Logistics & Supply Chain – High-productivity loading and unloading
Frequently Asked Questions
Q: How does the TKE Series improve energy efficiency?
A: The TKE Electric Counterbalance Forklift incorporates electric dedicated tires for reduced rolling resistance (10%+ energy savings), LED lighting (80%+ energy savings), and professionally matched components that extend battery life by approximately 10%.
Q: Is the Electric Counterbalance Forklift suitable for narrow aisle operations?
A: Yes. With right-angle stacking aisle widths ranging from 3,050 mm (TKE10) to 5,367 mm (TKE50) and tight turning radii from 1,690 mm, the TKE Series is designed for maneuverability in confined spaces.
Q: What maintenance access does the TKE Series provide?
A: The side panel of the frame can be removed for direct access to the electronic control system, simplifying inspection and repair procedures.
