12–20 Ton Diesel Forklift Truck

Model: CPCD
Load Capacity: 12,000 kg – 20,000 kg
Lift Height: 3,000 mm (Standard)
Mast Options: Two-Stage or Three-Stage Mast (Optional)
Drive Type: Front-Wheel Drive (Diesel Engine)
Operator Type: Seated (Ergonomic Semi-Enclosed Seat / Cab Optional)
Power Options: Diesel Engine (Turbocharged)
Minimum Order Quantity: 1 unit
Warranty Period: 1 year

Quantity:
Availability:





Inquire

Model:
CPCD
Brand:
NOELIFT

Products Detail

12–20 Ton Diesel Forklift Truck

Robust Performance, Superior Efficiency, and Ultimate Reliability for Heavy Industry

Our 12-20 ton diesel forklift is designed for continuous heavy-duty material handling. With robust chassis, large tires, strong lifting capacity and stable operation, it is suitable for demanding working conditions such as ports, terminals, steel mills, stone factories, construction material yards, logistics parks and mining areas.

Technical Specifications

Item	Unit	CPCD120	CPCD160	CPCD180	CPCD200
Rated Load	Q(Kg)	12000	16000	18000	20000
Load Center	c(mm)	600	900	900	900
Wheelbase	y(mm)	2950	3600	3800	4050
Weight	kg	16000	21000	25000	25000
Mast/Carriage Tilt Angles	Degree(°)	6/12	6/12	6/12	6/12
Mast Height (Fork Lowering)	h1(mm)	2940	3460	3500	3480
Standard Lifting Height	h2(mm)	3000	3500	3500	3500
Max Height During Operation	h3(mm)	4440	5180	5220	5200
Height to Head Guard / Cab	h4(mm)	2700	3365	3220	3300
Overall Length (With Forks)	L3(mm)	6130	7200	7400	8000
Face to Rear End Distance	L2(mm)	4530	5180	5600	6000
Overall Width	b1(mm)	2230	2550	2750	2550
Fork Dimension	mm	160018090	180020090	180024090	2200220100
Fork Carriage Width	b2(mm)	2080	2500	2500	2500
Min. Ground Clearance (Loaded)	m1(mm)	300	270	270	270
Wheelbase Center Clearance	m2(mm)	350	310	210	350
Min. Turning Radius	Wa(mm)	4350	5050	5300	5600
Travel Speed (Loaded/Unloaded)	km/h	23/28	22/30	22/30	26/30

Key Features

Low-Fuel Turbocharged Engine

Equipped with a low-fuel turbocharged engine, it delivers excellent fuel economy and is ideal for long working hours.

Strong Power & Large Torque Reserve

Strong power performance and a large torque reserve make heavy-load starts, climbing, and continuous operation more stable and reliable.

Heavy-Duty Load Capacity: 12–20 Tons

Rated load from 12,000 kg to 20,000 kg, meeting the handling needs of large cargo, stone, steel, containers, and other heavy materials.

Robust Chassis & Large Tires

Heavy-duty chassis and large tires provide strong overall stability, suitable for complex ground conditions such as ports, mines, and construction sites.

Optional Configurations

Optional mast heights, fork lengths, cabins, air conditioners, heaters, side shifters, clamps, and other attachments.

Applications

Ports & Terminals: Handling heavy containerized cargo, bulk steel, and heavy logistics elements.
Manufacturing & Heavy Industry: Transporting oversized machinery components, stone blocks, and structural metals.
Logistics & Warehousing Hubs: High-capacity yard transport requiring durable, all-weather diesel performance.

Certifications

Our Services

1. Pre-sales: One-on-one engineer customized solutions, free product manuals and operation videos provided;

2. During sales: Logistics tracking updated every 2 days, supporting multiple trade terms such as FOB/CIF/CFR;

3. After-sales: 1-year warranty on the whole machine, free parts delivered within 7 days during the warranty period, 24-hour uninterrupted technical support, and on-site debugging by local engineers worldwide.
