Cold Storage Pallet Truck

Optimize your freezer operations with our specialized Cold Storage Pallet Truck. Engineered to perform flawlessly in extreme low temperatures down to -30°C, this hand pallet jack features a low-temperature hydraulic system, food-grade stainless steel options, and non-slip polyurethane wheels for safe maneuvering on icy floors. Corrosion-resistant construction protects against condensation and washdowns. Ideal for meat processing, frozen food warehouses, and pharmaceutical cold chains. Keep your moving efficiently with our cold storage solutions.

Quantity:
Availability:





Inquire

Products Detail

Cold Storage Pallet Truck | Low-Temperature Electric Pallet Jack for Freezer Warehouses

Product SKU: CS-PT-25F | Certification: CE, ISO 9001, ATEX (Optional)
Operating Temperature: -30°C to +40°C | Load Capacity: 2.0T - 2.5T

Why Choose Our Cold Storage Pallet Truck?

Operating in sub-zero environments demands specialized equipment. Standard pallet trucks fail in freezing conditions—battery drain, hydraulic fluid thickening, and metal brittleness create costly downtime. Our Cold Storage Pallet Truck is engineered specifically for frozen warehouses, cold chain logistics, and refrigerated distribution centers.

Key Industries We Serve:

Frozen Food Processing Plants (-25°C operations)
Meat & Seafood Cold Storage Facilities
Pharmaceutical Cold Chain Logistics (GMP compliant)
Dairy & Ice Cream Distribution Centers
Port Cold Storage Terminals

Technical Specifications

Feature	Specification
Model Series	CS-PT 20F / 25F / 30F
Load Capacity	2,000 kg / 2,500 kg / 3,000 kg
Fork Length	1,150 mm / 1,220 mm (Customizable)
Fork Width	540 mm / 685 mm
Min. Fork Height	85 mm
Max. Lift Height	200 mm
Battery Type	Low-Temperature Lithium-Ion (-30°C rated)
Battery Capacity	150Ah / 210Ah
Operating Hours	6-8 hours continuous (freezer environment)
Charging Time	2-3 hours (fast charge available)
Drive Motor	AC Drive, IP67 waterproof rating
Hydraulic System	Low-temp hydraulic oil (-40°C pour point)
Body Material	Galvanized steel + Stainless steel options
Tire Type	Polyurethane (Cold-resistant, non-marking)
Gradeability	8% laden, 15% unladen
Turning Radius	1,450 mm

Cold Environment Engineering Features

Low-Temperature Battery System

Heated Battery Compartment: Maintains optimal 15-25°C internal temperature even in -30°C freezers
Thermal Management: Prevents capacity loss common in standard lithium batteries
Cold-Crank Performance: Instant start capability at -30°C without pre-heating

Arctic-Grade Hydraulics

Synthetic Hydraulic Oil: Pour point -40°C, maintains fluidity in extreme cold
Sealed Cylinder Design: Prevents moisture ingress and ice formation
Corrosion-Resistant Coating: Zinc-nickel plating on all hydraulic components

Structural Integrity

Galvanized Chassis: 80μm hot-dip galvanization resists salt spray and condensation corrosion
Stainless Steel Hardware: Grade 304 fasteners prevent rust in high-humidity cold rooms
Impact-Resistant Covers: Reinforced polymer guards protect vital components from forklift collisions

Operator Comfort & Safety

Heated Handle Option: Ergonomic grip with 12V heating element
Anti-Slip Platform: Textured stainless steel deck prevents ice buildup
LED Lighting: Low-temperature rated LED headlights for dark freezer aisles
Emergency Reverse: Automatic reverse function upon handle release

Compliance & Certifications

✅ CE Marked – EU Machinery Directive 2006/42/EC
✅ ISO 9001:2015 – Quality Management System
✅ ATEX Zone 2 (Optional) – For explosive atmosphere cold storage
✅ IP67 Protection – Dust-tight and immersion resistant
✅ RoHS Compliant – Environmentally friendly materials

Customization Options

Option	Description
Stainless Steel Version	Full 304/316 SS construction for food-grade applications
Explosion-Proof Model	ATEX certified for flammable cold storage (ammonia systems)
Weighing Scale Integration	Built-in load cell system ±1kg accuracy
Fleet Management System	GPS tracking, usage analytics, maintenance alerts
Special Fork Sizes	Custom length/width for unique pallet configurations
Additional Battery Packs	Hot-swappable battery system for 24/7 operations

Maintenance & Warranty

Standard Warranty: 12 months / 2,000 hours (whichever comes first)
Extended Warranty: Up to 36 months available

Cold Storage Maintenance Package Includes:

·Quarterly hydraulic system inspections

·Battery thermal management calibration

·Corrosion protection treatment

·24/7 technical support hotline

Global Shipping & Logistics

Export Packaging: Vacuum-sealed moisture barrier + ISPM-15 wooden crate
Shipping Terms: FOB Shanghai/Ningbo, CIF, DDP available
Lead Time: 15-25 days for standard models, 30-45 days for custom builds
Service Network: Authorized dealers in 40+ countries including USA, Germany, Australia, Brazil, Thailand

FAQ – Cold Storage Pallet Trucks

Q: Can this pallet truck operate in blast freezers (-40°C)?
A: Yes, our CS-PT-EXT series is specially designed for ultra-low temperatures down to -40°C with enhanced battery heating and arctic-grade components.

Q: How often does the hydraulic oil need changing in cold environments?
A: We recommend every 1,000 operating hours or 12 months, whichever comes first—our synthetic oil maintains performance 3x longer than standard mineral oils.

Q: Is the battery safe for use in food storage areas?
A: Absolutely. Our lithium iron phosphate (LiFePO4) batteries are sealed, maintenance-free, and emit no gases during charging or operation.

Q: Do you provide spare parts for international customers?
A: Yes, we maintain regional spare parts hubs in North America, Europe, and Southeast Asia with 48-hour shipping commitment for critical components.
