1.5–1.8 Ton Electric Counterbalance Forklift

Model: ESB Series
Load Capacity: 1,500 kg – 1,800 kg
Lift Height: 3,000 mm – 4,800 mm
Mast Options: Two-Stage or Three-Stage H-Section Steel Mast
Drive Type: Front-Wheel Drive
Operator Type: Seated
Power Options: 48 V / 135 Ah or 48 V / 200–280 Ah Battery
Side Shift: Optional
Minimum Order Quantity: 1 unit
Warranty Period: 1 year

Quantity:
Availability:





Inquire

Model:
ESB
Brand:
NOELIFT

Products Detail

1.5–1.8 Ton Electric Forklift for Warehouse & Material Handling

The ESB Series Electric Counterbalance Forklift is a compact seated electric forklift designed for efficient material handling, pallet transportation, and stacking operations. With rated load capacities of 1.5–1.8 tons and lift heights from 3.0 to 4.8 meters, the ESB series offers multiple mast and side-shift configurations to meet different warehouse and industrial handling requirements.

Designed for maneuverability in space-limited working environments, the ESB Series features a front-wheel-drive configuration, hydraulic steering, rubber tires, and a compact turning radius. As a 3 wheel counterbalance forklift, it provides smooth handling and precise maneuverability for pallet transport and stacking, making it suitable for warehouses, manufacturing facilities, logistics centers, distribution operations, and other indoor or covered material-handling environments.

Technical Specifications

Model	ESB
Product Type	Electric Counterbalance Forklift
Operator Type	Seated
Drive Type	Front Drive
Rated Load Capacity	1,500–1,800 kg
Load Center	400 mm
Mast Type	H-Section Steel
Mast Configuration	Two-Stage / Three-Stage
Lift Height	3,000–4,800 mm
Side Shift	Optional
Tire Type	Rubber
Travel Speed, Loaded	8.0 km/h
Travel Speed, Unloaded	9.0 km/h
Lift Speed, Loaded	184 mm/s
Lift Speed, Unloaded	194 mm/s
Gradeability	10%
Drive Motor	3.5–6 kW
Lift Motor	4 kW
Battery	48 V / 135 Ah or 48 V / 200–280 Ah
Hydraulic Brake	Standard
Fork Length	1,070 mm
Fork Minimum Height	80 mm
Ground Clearance	90 mm
Fork Tilt Angle	3° / 5°
Minimum Turning Radius	Approx. 1,603–1,733 mm

Key Configuration Highlights

Flexible Mast Options: Offers a range of two-stage and three-stage mast configurations, along with various combinations featuring optional sideshift capabilities, easily meeting the demands of racking operations at different heights.
High-Strength, Safe Structure: Comes standard with a robust H-beam mast and premium rubber tires; the scientifically optimized center of gravity ensures stability and safety during full-load operations.
Exceptional Maneuverability: Features a minimum turning radius starting at just 1603mm; combined with a compact chassis width and optimized right-angle stacking aisle dimensions, it navigates freely through narrow aisles and high-density storage areas.
High-Performance Power Output: Delivers powerful lifting and lowering speeds alongside stable full-load gradeability (10%), significantly boosting efficiency in daily loading, unloading, and material handling tasks.

Application Scenarios

Our compact electric forklift is widely used in global various industries and narrow working spaces:

Small & medium warehouses, logistics distribution centers
E-commerce fulfillment stations, express transfer centers
Supermarkets, retail stores and cold chain storage
Food, pharmaceutical, electronics and precision manufacturing workshops
Basements, elevators and other confined space handling
Textile, printing and furniture factories
