Counterbalance Pallet Stacker

Welcome to our professional Counterbalance Pallet Stacker page! As a reliable manufacturer specializing in material handling equipment, we design and produce high-performance counterbalance pallet stackers that meet global industrial standards. Our products are widely used in warehouses, factories, logistics centers, cold storage, and retail stores, helping you optimize material handling processes, improve work efficiency, and reduce operational costs. With stable performance, ergonomic design, and strict quality control, our counterbalance pallet stackers have been exported to more than 50 countries and regions, winning trust from customers worldwide.

Quantity:
Availability:





Inquire

Products Detail

Counterbalance Pallet Stacker - High Efficiency, Safety & Durability for Industrial Material Handling

Welcome to our professional Counterbalance Pallet Stacker page! As a reliable manufacturer specializing in material handling equipment, we design and produce high-performance counterbalance pallet stackers that meet global industrial standards. Our products are widely used in warehouses, factories, logistics centers, cold storage, and retail stores, helping you optimize material handling processes, improve work efficiency, and reduce operational costs. With stable performance, ergonomic design, and strict quality control, our counterbalance pallet stackers have been exported to more than 50 countries and regions, winning trust from customers worldwide.

Why Choose Our Counterbalance Pallet Stacker?

Our Counterbalance Pallet Stacker is the ideal alternative to traditional forklifts, designed to solve space constraints while maintaining heavy-duty performance.

1. Powerful Lifting & High Efficiency ⚡

Capacity: 2,000 lbs to 4,000 lbs load range.
Max Lift: Up to 180 inches (4572mm) with a 24V high-torque motor.
Speed: 37 fpm lift speed with a pressure-compensated hydraulic system for smooth, controlled lowering and faster cycle times.

2. No Outriggers, Max Maneuverability

Compact Footprint: Only 34.1" (866mm) wide with a tight 1738mm turning radius.
Versatile Loading: Unlike straddle stackers, our counterbalance design requires no base legs, allowing it to handle both closed-bottom and open-bottom pallets in aisles as narrow as 9-10 ft.

3. Ergonomic & Effortless Control

User-Friendly Handle: Multi-function ergonomic handle with dual thumbwheels reduces operator fatigue.
Smooth Ride: Spring-loaded torsion bar suspension and automatic load sensing ensure stability on uneven surfaces.
High Visibility: Wide-view mast design allows for precise fork positioning and enhanced safety.

4. Industrial Durability & Easy Service ️

Rugged Build: Heavy-duty steel construction with leak-proof cast iron pump bodies and durable PU/Rubber wheels.
Zero-Tool Maintenance: Quick-access service door allows for instant inspection of all major components, minimizing downtime and costs.

5. Multi-Layer Safety Protection ️

Built-in Safety: Emergency disconnect, automatic circuit breakers, and mechanical drum brakes come standard.
Load Security: Pressure overload relief valves and load backrest extensions prevent accidents during high-stacking operations.
Environment Ready: Custom options available for Cold Storage and harsh anti-corrosive environments.

Product Specifications

Model	Load Capacity	Lifting Height	Load Center	Overall Width	Turning Radius	Power Supply	Lift Speed
CB-2000	2000 lbs (0.9t)	120-180 inches (3048-4572mm)	24 inches (600mm)	34.1 inches (866mm)	1738mm	24V/210Ah Lead-Acid/Lithium Battery	37 fpm (11.3 m/min)
CB-3000	3000 lbs (1.36t)	120-180 inches (3048-4572mm)	24 inches (600mm)	36 inches (914mm)	1872mm	24V/270Ah Lead-Acid/Lithium Battery	37 fpm (11.3 m/min)
CB-4000	4000 lbs (1.8t)	120-160 inches (3048-4064mm)	24 inches (600mm)	38 inches (965mm)	1950mm	24V/350Ah Lead-Acid/Lithium Battery	35 fpm (10.7 m/min)

Note: Customization of load capacity, lifting height, and other parameters is available according to your specific needs. Please contact us for detailed customization solutions.

Wide Application Scenarios

Our counterbalance pallet stacker is designed to adapt to various industrial and commercial scenarios, providing efficient material handling solutions for different industries:

Warehousing & Logistics: Ideal for stacking and transporting pallets in narrow-aisle warehouses, improving storage utilization and logistics efficiency. It can be seamlessly integrated with WMS systems for intelligent scheduling, reducing empty driving rate by 25%.
Cold Storage: Equipped with low-temperature resistant battery and hydraulic oil, suitable for working in -30℃ extreme environments, with continuous operation capacity of 8 hours and remaining power over 20%.
Manufacturing: Perfect for material distribution between production lines, feeding materials into machines, and stacking finished products. It helps narrow production channel width, release effective production area, and improve unit产值 density by 38%.
Retail & Distribution: Suitable for small and medium-sized warehouses and retail backends, handling goods such as food, beverages, and daily necessities efficiently.
Heavy Industry: For handling heavy loads in metallurgy, papermaking, and other industries, with high stability and durability, realizing 24-hour continuous operation with failure rate lower than 0.3%.

Product Advantages Compared with Competitors

Features	Our Counterbalance Pallet Stacker	Ordinary Stackers
Load Capacity	2000-4000 lbs, stable load-bearing	1000-3000 lbs, easy to overload
Maneuverability	Narrow body, small turning radius, suitable for narrow aisles	Large body, poor maneuverability in narrow spaces
Maintenance	No-tools service door, easy maintenance, low downtime	Complex disassembly, high maintenance cost
Safety	Multiple safety protections, high-visibility mast	Basic safety features, poor visibility
Adaptability	Suitable for cold storage, heavy industry, narrow aisles, etc.	Limited application scenarios

Quality Assurance & After-Sales Service

Quality Commitment

All our counterbalance pallet stackers pass strict quality inspection before leaving the factory, complying with ISO9001, CE, and UL standards. We use high-quality components from well-known brands to ensure stable performance and long service life. The chassis and mast are made of high-strength steel with anti-corrosion treatment, adapting to harsh working environments.

After-Sales Service

1-year warranty for the whole machine, 2-year warranty for the motor and battery (subject to terms and conditions).
24/7 online technical support: Our professional technical team provides timely solutions for installation, operation, and maintenance issues.
Spare parts supply: We have a global spare parts warehouse, ensuring fast delivery of spare parts to reduce your downtime.
On-site service: We can arrange professional engineers to provide on-site installation, debugging, and training services according to your needs.

Counterbalance Pallet Stacker – No Legs, No Limits

【Legless Design】: No straddle legs means you can handle any pallet type – double-face, single-face, non-standard, or custom pallets. Complete freedom for diverse warehouse needs .
【Electric Operation】: Full electric travel and lift with AC drive motor. Smooth acceleration, regenerative braking, and low maintenance .
【1000kg-1500kg Capacity】: Available in 1-ton to 1.5-ton load capacities. Lifting heights up to 3500mm for versatile stacking applications .
【Walkie or Stand-On】: Choose pedestrian-controlled walkie model for short distances, or stand-on version with foldable pedal for longer operations .
【Advanced Controller】: Curtis or ZAPI AC controller for precise speed control, diagnostics, and multiple automatic protection systems .
【Lithium Battery Option】: Optional maintenance-free lithium-ion battery with fast charging and long cycle life. No battery changing required .
【Compact & Maneuverable】: Tight turning radius and compact dimensions for operation in narrow aisles and confined spaces .
【Safety Features】: Emergency stop, electromagnetic parking brake, anti-sliding function, and descent buffer protection. CE certified .

FAQ

Q1: What is the difference between a counterbalance pallet stacker and a regular pallet stacker?

A: The counterbalance pallet stacker uses the weight of the machine itself to balance the load, without the need for outrigger legs. This allows it to get closer to loads, access narrow aisles, and handle both closed-bottom and open-bottom pallets, which regular stackers with outriggers cannot do.

Q2: Can it be used outdoors?

A: Yes, we offer outdoor models with waterproof and dustproof design, suitable for outdoor loading and unloading operations. The cab models can provide protection against rain and harsh temperatures, ensuring stable operation in outdoor environments.

Q3: Is it easy to operate? Do operators need professional training?

A: Our counterbalance stacker is designed with user-friendly controls, simple to learn and operate. Unlike forklifts, it does not require professional certification, but we still recommend basic operation training to ensure safety and efficiency. We provide free online training materials and on-site training services if needed.

Q4: Can we customize the product according to our specific needs?

A: Yes, we support full customization, including load capacity, lifting height, battery type (lead-acid or lithium), fork size, and special designs for cold storage, heavy industry, etc. Please contact us with your specific requirements, and we will provide a tailored solution.

Contact Us

If you are interested in our counterbalance pallet stacker or have any questions, please feel free to contact us. We will reply to you within 24 hours and provide you with detailed product information, quotation, and customization solutions.
