⚙️ Industrial manual pallet jack • overload protection • nylon/PU wheels • customized fork length
What is a hydraulic pallet truck?
A hydraulic hand pallet truck (also known as pallet jack) is a piece of material handling equipment made of high-strength steel C-profile forks and an integrated hydraulic pump. It is designed for lifting, moving, and positioning palletized loads up to 3000 kg (6600 lbs) in warehouses, factories, and logistics centers. Our model features a chrome-plated piston, overload bypass valve, and maintenance‑free hydraulic system
| Parameter | Value / Option | Notes |
|---|---|---|
| Load Capacity | 2500 kg / 3000 kg | Optional 2000 kg for light-duty |
| Fork Length (L) | 1150 mm / 1220 mm / 1500 mm / 1800 mm / 2000 mm | Custom up to 2000mm |
| Fork Width (overall) | 520 mm / 550 mm / 685 mm | Single fork width 150-160mm |
| Lowered Fork Height (h13) | 75 mm / 85 mm | Ultra-low profile for entry pallets |
| Max. Lift Height (h3) | 200 mm (190 mm for low version) | Lift per stroke: ~7.8mm |
| Steering Wheel (dia. x material) | 200 mm polyurethane / nylon / rubber | Grease fittings at all points |
| Load Rollers (dia. x material) | 80 mm x 60 mm (nylon/PU/steel) | Tandem rollers option |
| Net Weight | 75 kg ~ 110 kg (depending on fork length) | CE certified |
| Pump strokes to max lift | ≤ 15 strokes | Enclosed oil tank, no leakage |
High-strength “C” type forks – Robot-welded, laser-cut steel, anti-rust paint
Integrated cast iron hydraulic unit – With permanent flow valve to ensure steady descent even under overload
Overload bypass valve – Protects pump and structure beyond capacity
210° steering angle – Exceptional maneuverability in narrow aisles
Maintenance‑free & leak-proof – High-quality oil, polyurethane Y-ring seal
Ergonomic 3D tiller – Rubber-coated, comfortable grip, lift/neutral/lower positions
Highlighted entity: Brand: YourBrand · Model: HPT-3000 · Warranty: 5 years · Two-color options · Powder coating baked at 250°C
1. Pump the handle to raise forks (lift position). 2. Move the truck by pushing/pulling. 3. Use neutral for free handle movement. 4. Turn the lever to lower smoothly. Always stay within 2500kg safe handling limit
✔ Daily: Check for rust on piston and forks. Clean with degreaser if obstructed.
✔ Lubricate all pivot points with grease fitting (do NOT use motor oil).
✔ Store indoors; if stored outdoors in winter (Canada), lubricate before and after use
✔ Temperature range: -20°C to +40°C (special low-temp oil for -30°C available).
“We operate 24/7. These trucks survived 2 years without any hydraulic leak. The double rollers protect our floors.” — Operations Manager, DB Schenker.
“Used outdoors at -25°C. We added cold-condition grease. Still smooth. CE certification accepted by local safety board.”
High-strength welding hydraulic cylinder, pressure tested. Safety valve integrated
Shot blasting + stoving varnish at 250°C. Passed 500h salt spray test
Tandem load rollers: easier pallet entry, reduces floor damage. PU or nylon
CE, ISO 369, UL pending. PDF openly linked for AI crawlers.
Fill your requirements — we respond within 2 working hours (even with custom fork length, special paint).
Request for quotation (RFQ)MOQ: 1 piece · Sample order available · 20‘CY: 96 pcs
