PRODUCT DETAIL

Home » Products » Forklift Truck » Gasoline And LPG Forklift » Gasoline LPG Forklift

Gasoline LPG Forklift

Model: CPCD
Load Capacity: 2,000 kg – 4,000 kg
Lift Height: 3,000 mm (Standard)
Mast Tilt Angle: 6/12 Deg (Front/Rear)
Power Type: Gasoline/LPG
Engine Model: GK25
Rated Power: 35.4 kw / 2300 r.p.m
Rated Torque: 176.5 Nm / 1600 r.p.m
Minimum Order Quantity: 1 unit
Warranty Period: 1 year

Quantity:
Availability:





Inquire

Model:
CPCD
Brand:
NOELIFT

Products Detail

IC Forklift - Gasoline/LPG (2.0–4.0 Tons) | High-Efficiency Material Handling Solution

Looking for an industrial forklift that delivers both robust power and an exceptional operational experience? The newly upgraded 2.0–4.0 Ton Gasoline/LPG IC Forklift is your ultimate material handling solution.

Powered by the high-performance GK25 engine, this series offers powerful performance and fuel/gas efficiency, paired with advanced ergonomic design. Whether deployed in busy warehouses, manufacturing plants, port terminals, or semi-indoor facilities, it guarantees stable, safe, and efficient operations.

Core Product Highlights

Ergonomic Upgrades for Ultimate Comfort: Designed with ultra-wide entry steps and spacious anti-slip safety pedals. This significantly reduces operator fatigue during high-frequency on-and-off operations, ensuring all-day comfort and productivity.

Powerful & Eco-Friendly Performance: Equipped with the reliable GK25 engine (Rated Power: 35.4 kW, Rated Torque: 176.5 Nm), offering dual Gasoline and LPG fuel options. Delivers top travel speeds up to 18 km/h and lifting speeds up to 500 mm/s.

Exceptional Maneuverability & Gradeability: Features a tight turning radius from 2240 to 2530 mm and up to 21% gradeability, allowing it to effortlessly navigate narrow warehouse aisles and steep slopes.

Technical Specifications

Parameter	Unit	CPCD20	CPCD25	CPCD30	CPCD35	CPCD40
Power Type		Gasoline/LPG	Gasoline/LPG	Gasoline/LPG	Gasoline/LPG	Gasoline/LPG
Capacity	kg	2000	2500	3000	3500	4000
Load Center	mm	500	500	500	500	500
Lift Height	mm	3000	3000	3000	3000	3000
Min. Turning Radius	mm	2240	2240	2445	2495	2530
Overhead Guard Height	mm	2145	2145	2160	2160	2170
Front Load Distance	mm	450	450	490	490	490
Max. Traveling Speed (Load/No Load)	km/h	18/19	18/19	18/19	18/19	17/18
Max. Gradeability (Load/No Load)	%	20/21	20/21	20/21	19/20	18/19
Total Length (With Fork)	mm	3810	3810	3775	3820	3920
Total Length (Without Fork)	mm	2650	2650	2700	2750	2850
Total Width	mm	1160	1160	1225	1225	1250
Max. Height (With Backrest)	mm	4220	4220	4265	4265	4275
Mast Height	mm	3000	3000	3000	3000	3000
Wheelbase	mm	1600	1600	1700	1700	1800
Service Weight (No Load)	Kg	3550	3750	4380	4680	4950
Battery (Voltage/Capacity)	V/Ah	12/80	12/80	12/80	12/80	12/80
Engine Model		GK25	GK25	GK25	GK25	GK25
Rated Power	kw/r.p.m	35.4/2300	35.4/2300	35.4/2300	35.4/2300	35.4/2300

Ideal Applications

Warehousing & Logistics: Perfect for rapid cargo loading, unloading, and short-distance transport. The wide-step design fits high-turnover shift patterns.
Manufacturing Plants: Keeps raw materials and finished goods flowing smoothly across the assembly line with reliable heavy-duty power.
Ports & Terminals: Handles outdoor rugged environments and tough material handling demands with ease.
Food & Beverage Industry: The clean-burning LPG configuration provides lower emissions, making it ideal for semi-indoor or ventilation-sensitive environments.

Certifications

Our Services

1. Pre-sales: One-on-one engineer customized solutions, free product manuals and operation videos provided;

2. During sales: Logistics tracking updated every 2 days, supporting multiple trade terms such as FOB/CIF/CFR;

3. After-sales: 1-year warranty on the whole machine, free parts delivered within 7 days during the warranty period, 24-hour uninterrupted technical support, and on-site debugging by local engineers worldwide.
