TQ
NOELIFT
The TQ series Multi-Directional Forklift is engineered to revolutionize heavy-duty material handling in confined spaces. Offering a lift height range of 3.0m to 8.0m and a robust rated load capacity of 3,000 kg, this advanced electric forklift transcends the limits of standard reach trucks.
Featuring cutting-edge multi-directional travel modes—including straight, lateral, diagonal, right-angle turns, and in-situ 360° spin—the TQ series excels at navigating restricted corridors while effortlessly transporting oversized and long cargo such as steel bars, metal profiles, timber, and large panels.
Multi-Directional Navigation: Seamlessly switch between forward travel, lateral crabbing, and diagonal steering to maneuver effortlessly through tight warehouse layouts.
Specialized for Long Materials: The lateral driving mode enables safe and balanced handling of extra-long cargo (metal profiles, pipes, and sheets) that standard forklifts cannot navigate.
High-Reach Capacity: Achieve vertical storage heights from 3.0m up to 8.0m without compromising stability or lifting power.
Space-Saving Design: Narrow body construction designed specifically to maximize high-density storage in narrow aisle racking systems.
Model | TQ |
Rated Load Capacity | 3,000 kg |
Fork Dimensions (L × W × T) | 1,200 × 125 × 50 mm |
Overall Length, Without Guide Wheel | 2,000 mm |
Overall Width | 2,280 / 2,860 mm |
Maximum Lift Height | 8,000 mm |
Minimum Turning Radius | 3,400 mm (unladen) |
Battery | 48V / 300Ah |
Fork Carriage Width | 2,860 mm |
Reach Distance | 1,300 mm |
Fork Outside Distance | 2,800–5,600 mm |
Steel and Metal Processing Centers (handling steel bars and profiles)
Lumber and Wood Yards (handling long panels and timber)
Heavy Manufacturing & Warehousing with Narrow Aisles
Logistics hubs specializing in oversized and irregular cargo storage
1. Pre-sales: One-on-one engineer customized solutions, free product manuals and operation videos provided;
2. During sales: Logistics tracking updated every 2 days, supporting multiple trade terms such as FOB/CIF/CFR;
3. After-sales: 1-year warranty on the whole machine, free parts delivered within 7 days during the warranty period, 24-hour uninterrupted technical support, and on-site debugging by local engineers worldwide.
