Self Load Stacker for Vans And Trucks

500-1500kg Capacity | lift heights up to 3500mm | One-Person Operation | Save 50% Labor Costs

Self Load Stacker – electric travel + electric lift. Compact design for narrow aisles. Maintenance-free battery, CE certified. Factory direct prices.

Quantity:
Availability:





Inquire

Products Detail

Portable Self-Load Stacker | Electric Self-Lifting Pallet Jack for Vans & Trucks

1.Product Introduction

Tired of waiting for a forklift at your delivery destination? Our Self-Load Stacker (also known as a self-lifting forklift) is the ultimate solution for urban logistics and distribution. This innovative equipment can lift itself into the back of a van, truck, or trailer along with the cargo. No more heavy manual lifting or dependence on expensive tail lifts and warehouse forklifts.

2.Key Features & Advantages

Self-Lifting Capability: Unique design allows the stacker to lift itself into the vehicle effortlessly.
Compact & Lightweight: Fits perfectly in the back of Sprinter vans, Ford Transits, and various delivery trucks without taking up excessive cargo space.
All-in-One Solution: Replaces the need for a tail lift, pallet jack, and ramp, significantly reducing equipment costs.
Powerful Electric Lift: Equipped with a high-performance 12V/45Ah maintenance-free battery and a 0.8kW motor for smooth lifting.
Ergonomic & Safe: Features an emergency stop button, protective chain guards, and a reinforced mast for operator safety and machine durability.
Multi-Surface Compatibility: High-quality nylon or PU wheels ensure smooth movement on warehouse floors and truck beds.

3.Technical Specifications

Feature	Manual Stacker	Semi-Electric Stacker	Self Load Stacker (Ours)	Full Electric Stacker
Travel Power	Manual push	Manual push	Electric motor	Electric motor
Lift Power	Manual pump	Electric motor	Electric motor	Electric motor
Operator Effort	High	Medium (lift only)	Low	Low
Battery Maintenance	None	Low (lift only)	Low	Medium
Typical Capacity	1000-2000kg	500-1500kg	500-1500kg	1000-2000kg
Best For	Occasional use	Budget lifting	All-around efficiency	High-volume ops

Comparison based on industry standards and manufacturer data .

Manufacturer			NOELIFT
Model			CDD05Z
Operation			Manual Driving, Electrical Lifting
capacity	kg	500	500	500
loading center	mm	400	400	400
wheelbase	mm	860	860	860
front wheel distance	mm	380	380	380
rear track	mm	670	670	670
min.fork height	mm	90	90	90
max.fork height	mm	800	1000	1300
steering wheel	mm	Φ100x45	Φ100x45	Φ100x45
loading wheel	mm	Φ70x60	Φ70x60	Φ70x60
overall length	mm	1600	1600	1600
overall width	mm	780	780	780
fork size	mm	1150*540	1150*540	1150*540
forkwidth	mm	535	535	535
turning radius	mm	1100	1200	1200
lifting speed	mm/s	80	80	80
descent speed	mm/s	90	90	90
lifting motor power	kw	12v/0.8	12v/0.8	12v/0.8
battery	V/AH	12/45	12/45	12/45
type of driving		pedestrian	pedestrian	pedestrian
material of wheel		Polyurethane	Polyurethane	Polyurethane
net weight	kg	193	200	219

4.Why Choose a Self-Load Stacker for Your Business?

For logistics companies and independent owner-operators, the Self-Load Stacker offers a massive return on investment (ROI):

Independent Delivery: One person can handle the entire loading and unloading process, saving 50% on labor costs.
Versatile Application: Ideal for moving heavy appliances, furniture, construction materials, and palletized goods directly to the customer's door.
No Tail Lift Needed: Save thousands of dollars by choosing a standard van and using our portable stacker instead of installing a permanent tail lift.

5. Maintenance & Quality Commitment

As a professional manufacturer of material handling equipment, we prioritize reliability:

Simplified Maintenance: The modular hydraulic and electrical system allows for easy troubleshooting and parts replacement.
Global Shipping: Securely packed in plywood crates to ensure the machine arrives in perfect condition.
1-Year Warranty: Includes full technical support and a fast-response spare parts service.

6.FAQ (Frequently Asked Questions)

Q: Can this stacker lift itself into a high-bed truck?
A: Our standard models support heights up to 1.3m. For higher beds, please contact us for customized mast options.
Q: How long does the battery last on a single charge?
A: On a full charge, it can typically handle 40-50 lifting cycles, sufficient for a full day of multi-drop deliveries.
Q: Is it easy to operate?
A: Yes, it features simple "Up/Down" controls. We provide a video tutorial to help you master the self-lifting process in minutes.
Q: What’s the MOQ and delivery time?

A: MOQ 1 unit, delivery time 7-15 working days for standard models.

Q: Do you support custom mast height for high-bed trucks?

A: Yes, custom mast up to 3500mm is available.

Q: How to get a video tutorial for operation?

A: Contact us to get the free operation video and user manual.
